    The Tesla Model X Wheel Guide

    Tesla Model X Wheel Guide, OEM, Aftermarket, and Mods

    Updated 04/29/2022

    View Model X Wheel Gallery Here

    Everything you need to know about your Tesla Model X Wheels.



    20 inch Tesla Model X Slipstream Wheel

    20" Tesla Model X Slipstream Wheel

    This was the wheel originally included as standard on all 2016 - 2020 Tesla Model X. The Tesla Model X Slipstream Wheel was only available in a silver or a Sonic Carbon color.

    Size: 20x9.0" Front, 20x10" Rear (Note: Tesla later changed rear wheel to 20x9.5"+35)
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 32 lbs Front, 33.2 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: No Charge for Silver or $4,300 for Sonic Carbon
    Tire Spec: Continental CrossContact LX Sport - 265/45R20 108V XL Front, 275/45ZR20 110V XL Rear (Overall Diameter: 29.4" Front, 29.7" Rear / Revolutions Per Mile: 707 Front, 698 Rear)


    22 inch Tesla Model X Turbine Wheel

    22" Tesla Model X Turbine Wheel

    The Turbine Wheel was the an optional wheel upgrade for the Model X. The Model X Turbine Wheel was the first iteration of the Turbine Wheel. The Turbine was only available in Silver or Onyx Black color.

    Size: 22x9.0" Front, 22x10.0" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 37.6 lbs Front, 40.4 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $5,500
    Tire Spec: Pirelli Scorpion Zero All Season - 265/35ZR22 102Y Front, 285/35ZR22 106Y XL (Overall Diameter: 29.3" Front, 29.9" Rear / Revolutions Per Mile: 708 Front, 695 Rear)


    19 inch Tesla Model X Cyclone Wheel

    19" Tesla Model X Cyclone Wheel

    The Cyclone Wheel was offered to Tesla Model X owners through the Tesla online store as a winter wheel and tire package for the price of $4,400. The Cyclone was only available in Silver color.

    Size: 19x8.5"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $4,400
    Tire Spec: Pirelli Scorpion Winter - 265/50R19 110V XL (Overall Diameter: 29.7")


    20 inch Tesla Model X Helix Wheel

    20" Tesla Model X Helix Wheel

    The Helix Wheel was the an optional wheel upgrade for the Model X. The cost was $2,500.00 when ordering the Model X. The Helix was also offered as a wheel and tire package for $5,500.00 in the Tesla online store. The Helix was only available in Silver color.

    Size: 20x9.0" Front, 20x10.0" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 34 lbs Front, 35 lbs Rear (Estimated)
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $2,500
    Tire Spec: Continental CrossContact LX Sport - 265/45R20 108V XL Front, 275/45ZR20 110V XL Rear (Overall Diameter: 29.4" Front, 29.7" Rear / Revolutions Per Mile: 707 Front, 698 Rear)


    Offered by T Sportline:

    As the World's First Tesla Tuner, we engineer our wheels to fit within the factory parameters of your Model X. We use the hashtag motto #alloriginal, which means our wheels use the following:

    • The factory Tesla center caps. (COLOR MATCHED T Sportline center cap included with every wheel.)
    • The factory lug nuts
    • The factory tires.
    • The factory tire pressure sensors.

    The fact that we have designed all our wheels to fit all the factory hardware alleviates the need to fiddle with aftermarket lug nuts, branded center caps and different tire sizes. All you need to do is swap the wheels!

    19 inch Tesla Model X TST Tesla Aftermarket Wheel

    19" TSS Wheel - Flow Forged

    The T Sportline TSS wheel is intended for the Model X owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 19" TSS is load rated at 900 kg/1,980 lbs.

    Size: 19x8.5"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 23.7 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,100 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    19 inch Tesla Model X TST Tesla Aftermarket Wheel

    19" TST Wheel - Flow Forged

    The T Sportline TST wheel is intended for the Model X owner looking for a similar appearance to the first version 22" factory Turbine wheel on a 2016 - 2020 Model X. Each 19" TST is load rated at 900 kg/1,980 lbs.

    Size: 19x8.5"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 24.4 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,100 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    20 inch Tesla Model X TSV Tesla Aftermarket Wheel

    20" TSV Wheel - Flow Forged

    The T Sportline TSV wheel is intended for the Model X owner looking for a similar appearance to the 21" factory Uberturbine wheel on a Model Y. Each 20" TSV is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10.0" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 33 lbs Front, 35.05lbs Rear (Estimated)
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,600 per set of four
    Finishes: Satin Gray and Satin Black


    20 inch Tesla Model X TS5 Tesla Aftermarket Wheel

    20" TS5 Wheel - Flow Forged

    The T Sportline TS5 wheel is intended for the Model X owner looking for a similar appearance to the 20" factory Zero G wheel from the Tesla Model 3 Track Package. Each 20" TS5 is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10.0" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 26.75 lbs Front, 29.8 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,600 per set of four
    Finishes: Satin Gray and Satin Black


    20 inch Tesla Model X TSS Tesla Aftermarket Wheel

    20" TSS Wheel - Flow Forged

    The T Sportline TSS wheel is intended for the Model X owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 20" TSS is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29.7 Front, 30.45 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,500 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    20 inch Tesla Model X TST Tesla Aftermarket Wheel

    20" TST Wheel - Flow Forged

    The T Sportline TST wheel is intended for the Model X owner looking for a similar appearance to the first version 22" factory Turbine wheel on a 2016 - 2020 Model X. Each 20" TST is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 28.8 lbs Front, 31 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,100 for a set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    22 inch Tesla Model X TSV Tesla Aftermarket Wheel

    22" TSV Wheel - Flow Forged

    The T Sportline TSV wheel is intended for the Model X owner looking for a similar appearance to the 21" factory Uberturbine wheel on a Model Y. Each 22" TSV is load rated at 900 kg/1,980 lbs.

    Size: 22x9.0" Front, 22x10.0" Rear
    Offset: +30
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 39.45 lbs Front, 41.5 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $3,000 per set of four
    Finishes: Satin Gray and Satin Black


    22 inch Tesla Model X TSS Tesla Aftermarket Wheel

    22" TSS Wheel - Flow Forged

    The T Sportline TSS wheel is intended for the Model X owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 22" TSS is load rated at 900 kg/1,980 lbs.

    Size: 22x9.0" Front, 22x10.0" Rear
    Offset: +30
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 32.15 lbs Front, 34.3 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,900 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    22 inch Tesla Model X MX114 Tesla Aftermarket Wheel

    22" MX114 Wheel - Fully Forged

    Size: 22x9.5" Front, 2xx10.5" Rear
    Offset: +30
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 31.3  lbs Front, 29.35 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,700 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    22 inch Tesla Model X MX117 Tesla Aftermarket Wheel

    22" MX117 Wheel - Fully Forged

    Size: 22x9.5" Front, 22x10.5" Rear
    Offset: +30
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29.87 lbs Front, 29.15 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,700 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    22 inch Tesla Model X MX118 Tesla Aftermarket Wheel

    22" MX118 Wheel - Fully Forged

    Size: 22x9.5" Front, 22x10.5" Rear
    Offset: +30
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 28.8 lbs Front, 30.4 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,700 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
