Updated 04/02/2025
View Model Y Juniper Wheel Gallery Here
Everything you need to know about your Tesla Model Y Wheels on your Tesla Model Y Long Range, and Performance.
19" Tesla Model Y Crossflow Prime Wheel
This was the wheel originally included as standard on all Long Range Tesla Model Y Juniper Launch Series. This Tesla Model Y Wheel included a base 5-spoke wheel design with an Aero Wheel Cover attachment.
Size: 19x9.5"Offset: +45
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 29.4 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Tesla Option: No Charge
Tire Spec: Pirelli Scorpion MS - 255/45R19 104W XL (Overall Diameter: 28" / Revolutions Per Mile: 741)
20" Tesla Model Y Helix Prime 2.0 Wheel
This Tesla Model Y wheel was an optional wheel upgrade when ordering the current Model Y Juniper Launch Series as of March 2025. This is the largest Tesla Model Y wheel that can be ordered with a Long Range Launch Series. The Tesla Model Y Helix Prime 2.0 Wheel is available in a silver finish with a 1-pc star shaped cap.
Size: 20x9.5"Offset: +45
PCD: 5x114.3
Center Bore: 64.1mm
Weight: TBD
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Tesla Option: No Charge (As of March 2025)
Tire Spec: Michelin Pilot Sport EV 255/40R20 101W T0 XL (Overall Diameter: 28" / Revolutions Per Mile: 742).
Offered by T Sportline:
As the World's First Tesla Tuner, we engineer our wheels to fit within the factory parameters of your Model Y. We use the hashtag motto #alloriginal, which means our wheels use the following:
- The factory Tesla center caps. (COLOR MATCHED T Sportline center cap included with every wheel.)
- The factory lug nuts
- The factory tires.
- The factory tire pressure sensors.
The fact that we have designed all our wheels to fit all the factory hardware alleviates the need to fiddle with aftermarket lug nuts, branded center caps and different tire sizes. All you need to do is swap the wheels!
18" TSA Directional Wheel - Cast
The T Sportline TSA Directional wheel is intended for the Model Y owner looking for maximum range. Each 18" TSA is load rated at 750 kg/1,653 lbs.
Size: 18X8.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 28.42 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,650 per set of four
Finishes: Satin Black
18" TSR Wheel - Flow Forged
The T Sportline TSR wheel is intended for the Model Y owner looking for a similar appearance to the Tesla Roadster wheel. Each 18" TSR is load rated at 750 kg/1,653 lbs.
Size: 18X8.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 22.5 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,640 per set of four
Finishes: Satin Gray and Satin Black
18" TS5 Wheel - Flow Forged
The T Sportline TS5 wheel is intended for the Model Y owner looking for a similar appearance to the 20" factory Zero G wheel from the Tesla Model 3 Track Package. Each 18" TS5 is load rated at 750 kg/1,653 lbs.
Size: 18X8.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 22 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,640 per set of four
Finishes: Cyber Silver, Satin Gray, and Satin Black
18" TSS Wheel - Flow Forged
The T Sportline TSS wheel is intended for the Model Y owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 18" TSS is load rated at 750 kg/1,653 lbs.
Size: 18X8.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 22.9 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,540 per set of four
Finishes: Brilliant Silver, Space Gray, Satin Black, and Gloss Black
18" TST Wheel - Flow Forged
The T Sportline TST wheel is intended for the Model Y owner looking for a similar appearance to the first version 21" factory Turbine wheel on a Model S. Each 18" TST is load rated at 750 kg/1,653 lbs.
Size: 18X8.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 23.6 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,540 for a set of four
Finishes: Brilliant Silver, Space Gray, Satin Black, and Gloss Black.
18" TXL115 Wheel - Fully Forged
Size: 18X8.5" or 18x9.5"Offset: +35 (18x8.5") or +28 (18x9.5")
PCD: 5X114.3
Center Bore: 64.1mm
Weight: TBD
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $3,595 for a set of four
Finishes: Satin Black, Gloss Black, Anthracite Gray, Brush Satin, Diamond Black, and Custom Finishes
19" TSR Wheel - Flow Forged
The T Sportline TSR wheel is intended for the Model Y owner looking for a similar appearance to the Tesla Roadster wheel. Each 19" TSR is load rated at 900 kg/1,980 lbs.
Size: 19X9.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 26.55 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,160 per set of four
Finishes: Satin Gray and Satin Black
19" TSF Wheel - Flow Forged
The T Sportline TSF Wheel is inspired by the T Sportline Limited Edition Falcon Wheel that celebrated the success of Space X. Each 19" TSF is load rated at 800 kg/1,763 lbs.
Size: 19x9.5"Offset: +35
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 25.5 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,160 per set of four
Finishes: Space Gray, Satin Black, and Gloss Black
19" TSV Wheel - Flow Forged
The T Sportline TSV wheel is intended for the Model Y owner looking for a similar appearance to the 21" factory Uberturbine wheel on a Model Y Performance. Each 19" TSV is load rated at 800 kg/1,763 lbs.
Size: 19x9.5"Offset: +35
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 31.5 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,160 per set of four
Finishes: Satin Gray and Satin Black
19" TS5 Wheel - Flow Forged
The T Sportline TS5 wheel is intended for the Model Y owner looking for a similar appearance to the 20" factory Zero G wheel from the Tesla Model 3 Track Package. Each 19" TS5 is load rated at 800 kg/1,763 lbs.
Size: 19x9.5"Offset: +35
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 26 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,160 per set of four
Finishes: Satin Gray and Satin Black
19" TSS Wheel - Flow Forged
The T Sportline TSS wheel is intended for the Model Y owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 19" TSS is load rated at 800 kg/1,763 lbs.
Size: 19x9.5"Offset: +35
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 27.85 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,060 per set of four
Finishes: Space Gray, Satin Black, and Gloss Black
19" TST Wheel - Flow Forged
The T Sportline TST wheel is intended for the Model Y owner looking for a similar appearance to the first version 21" factory Turbine wheel on a Model S. Each 19" TST is load rated at 800 kg/1,763 lbs.
Size: 19x9.5"Offset: +35
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 26.95 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,860 for a set of four
Finishes: Brilliant Silver, Space Gray, Satin Black, and Gloss Black
19" Falcon Y Limited Edition Wheel - Flow Forged (Limited Edition Sold Out)
The T Sportline Falcon Y Limited Edition Wheel is inspired by the success of Space X and exclusively manufactured for the Tesla Model Y. Each 19" Falcon Limited Edition Wheel is load rated at 750 kg/1,650 lbs.
Size: 19x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 24.9lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: $2,000 for a set of four
Finishes: Ecliptic Black, Moonrock Gray, and Jupiter Bronze
19" TXL115 Wheel - Fully Forged
Size: 19X8.5" or 19x9.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: TBD
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $3,795 for a set of four
Finishes: Satin Black, Gloss Black, Anthracite Gray, Brush Satin, Diamond Black, and Custom Finishes
20" TSR Wheel - Flow Forged
The T Sportline TSR wheel is intended for the Model Y owner looking for a similar appearance to the Tesla Roadster wheel. Each 20" TSR is load rated at 650 kg/1,433 lbs.
Size: 20X10.0"Offset: +40
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 29.6 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,260 per set of four
Finishes: Satin Gray and Satin Black
20" TSF Wheel - Flow Forged
The T Sportline TSF Wheel is inspired by the T Sportline Limited Edition Falcon Wheel that celebrated the success of Space X. Each 20" TSF is load rated at 900 kg/1,980 lbs.
Size: 20x10.0"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 27.3 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,260 per set of four
Finishes: Space Gray, Satin Black, and Gloss Black
20" TSV Wheel - Flow Forged
The T Sportline TSV wheel is intended for the Model Y owner looking for a similar appearance to the 21" factory Uberturbine wheel on a Model Y. Each 20" TSV is load rated at 900 kg/1,980 lbs.
Size: 20x10.0"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 35.05lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,260 per set of four
Finishes: Satin Gray and Satin Black
20" TS5 Wheel - Flow Forged
The T Sportline TS5 wheel is intended for the Model Y owner looking for a similar appearance to the 20" factory Zero G wheel from the Tesla Model 3 Track Package. Each 20" TS5 is load rated at 900 kg/1,980 lbs.
Size: 20x10.0"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 29.8 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,260 per set of four
Finishes: Satin Gray, Satin Black, and Gloss Black
20" TSS Wheel - Flow Forged
The T Sportline TSS wheel is intended for the Model Y owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 20" TSS is load rated at 900 kg/1,980 lbs.
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 30.45 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,160 per set of four
Finishes: Space Gray, Satin Black, and Gloss Black
20" TST Wheel - Flow Forged
The T Sportline TST wheel is intended for the Model Y owner looking for a similar appearance to the first version 21" factory Turbine wheel on a Model S. Each 20" TST is load rated at 900 kg/1,980 lbs.
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 31 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $1,960 for a set of four
Finishes: Space Gray, Satin Black, and Gloss Black
20" Falcon Y Limited Edition Wheel - Flow Forged (Limited Edition Sold Out)
The T Sportline Falcon Limited Edition Wheel is inspired by the success of Space X and exclusively manufactured for the Tesla Model Y. Each 20" Falcon Limited Edition Wheel is load rated at 750 kg/1,650 lbs.
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 25.65 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: $2,400 for a set of four
Finishes: Ecliptic Black, Moonrock Gray, and Jupiter Bronze
20" TXL115 Wheel - Fully Forged
Size: 20x10"Offset: +38
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 21.45 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $3,995 for a set of four
Finishes: Satin Black, Gloss Black, Anthracite Gray, Brush Satin, Diamond Black, and Custom Finishes
20" TSC Wheel - Forged Carbon Fiber
Size: 20X9.5"Offset: +35
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 20x8.5": 20.25 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $6,995 for a set of four
Finishes: Gloss Carbon Fiber
20" TY114 Wheel - Fully Forged
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 25 lbs (Estimated)
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,000 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
20" TY115 Wheel - Fully Forged
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 25 lbs (Estimated)
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,000 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
20" TY117 Wheel - Fully Forged
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 26.9 lbs
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,000 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
20" TY118 Wheel - Fully Forged
Size: 20x10"Offset: +40
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 26 lbs (Estimated)
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,000 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
21" TS5 Wheel - Flow Forged
The T Sportline TS5 wheel is intended for the Model Y owner looking for a similar appearance to the 20" factory Zero G wheel from the Tesla Model Y Track Package. Each 21" TS5 is load rated at 850 kg/1,874 lbs.
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, +38 Rear
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 28.95 lbs Front, 30.05 lbs Rear
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $2,500 per set of four
Finishes: Satin Gray and Satin Black
21" TXL115 Wheel - Fully Forged
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, +38 Rear
PCD: 5X114.3
Center Bore: 64.1mm
Weight: 21x9.5": 25.9 lbs; 21x10.5": 27.0 lbs
Lug Nut Spec: 21mm Hex, 14X1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $4,295 for a set of four
Finishes: Satin Black, Gloss Black, Anthracite Gray, Brush Satin, Diamond Black, and Custom Finishes
21" TSSF Wheel - Fully Forged
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, + 38 Rear
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 30.2 lbs Front, 31.4 lbs Rear
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,400 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
21" TY114 Wheel - Fully Forged
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, + 38 Rear
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 29.2 lbs Front, 30 lbs Rear
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,400 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
21" TY115 Wheel - Fully Forged
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, + 38 Rear
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 27.55 lbs Front, 28.85 lbs Rear
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,400 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
21" TY117 Wheel - Fully Forged
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, + 38 Rear
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 28.5 lbs Front, 29.4 lbs Rear
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,400 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
21" TY118 Wheel - Fully Forged
Size: 21x9.5" Front, 21x10.5" RearOffset: +30 Front, + 38 Rear
PCD: 5x114.3
Center Bore: 64.1mm
Weight: 27.55 lbs Front, 28.85 lbs Rear
Lug Nut Spec: 21mm Hex, 14x1.50 Thread
Lug Nut Torque Spec: 129lb-ft
Price: Starting from $5,400 per set of four
Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black
