    The Tesla Model S Wheel Guide

    Tesla Model S Wheel Guide, OEM, Aftermarket, and Mods

    Updated 12/12/2022

    View Model S Wheel Gallery Here

    Everything you need to know about your Tesla Model S Wheels.



    19 inch Tesla Model S Aero Wheel

    19" Tesla Model S Tempest Aero Wheel

    This was the wheel originally included as standard on all Long Range and Plaid Tesla Model S. This Tesla Model S Wheel included a base split-7 wheel design with an Aero Wheel Cover attachment. The Tesla Model S Aero Wheel was only available in silver color.

    Size: 19x8.5" Front
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29.6 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: No Charge
    Tire Spec: Michelin Primacy MXM4 - 245/45R19 98W XL (Overall Diameter: 27.7" / Revolutions Per Mile: 751); Goodyear Eagle RS-A2 -245/45R19 98V XL (Overall Diameter: 27.7" / Revolutions Per Mile: 751)


    21 inch Tesla Model S Turbine Wheel

    21" Tesla Model S Twin Turbine Wheel

    This wheel was the last wheel option available when ordering a Tesla Model S in 2020. It came in a staggered set up. This wheel was available with a set of lug nut covers that only first this wheel design. The 21" Turbine was available in silver or gray color.

    Size: 21x8.5" Front, 21x9.0" Rear
    Offset: +40
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 33.8 lbs Front, 35.8 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $4,500 or $6,000 via Tesla Shop
    Tire Spec: Michelin Pilot Super Sport or Michelin Pilot Sport 4S tires - 245/35ZR21 96Y XL Front, 265/35ZR21 101Y XL (Overall Diameter: 27.8" Front, 28.3" Rear / Revolutions Per Mile: 747 Front, 734 Rear)


    19 inch Tesla Model S Slipstream Wheel

    19" Tesla Model S Slipstream Wheel

    The Slipstream Wheel was offered as a standard wheel option for the Tesla Model S to replace the original Tesla Model S Base Wheel in 2016. The Slipstream was only available in Silver or Sonic Carbon color.

    Size: 19x8.0"
    Offset: +40
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: No Charge for Silver or $1,500 for Sonic Carbon
    Tire Spec: Michelin Primacy MXM4 - 245/45R19 98W XL (Overall Diameter: 27.7" / Revolutions Per Mile: 751); Goodyear Eagle RS-A2 -245/45R19 98V XL (Overall Diameter: 27.7" / Revolutions Per Mile: 751)


    19 inch Tesla Model S Base Wheel

    19" Tesla Model S Base Wheel Wheel

    The Base Wheel was offered as the first standard wheel option for the Tesla Model S and was replaced by the Slipstream in 2016. The Base Wheel was only available in Silver in color.

    Size: 19x8.0"
    Offset: +40
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29.5 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: No Charge
    Tire Spec: Michelin Primacy MXM4 - 245/45R19 98W XL (Overall Diameter: 27.7" / Revolutions Per Mile: 751); Goodyear Eagle RS-A2 -245/45R19 98V XL (Overall Diameter: 27.7" / Revolutions Per Mile: 751)


    19 inch Tesla Model S Cyclone Wheel

    19" Tesla Model S Cyclone Wheel

    The Cyclone Wheel was offered to Tesla Model S owners through the Tesla online store as a winter wheel and tire package for the price of $4,400. The Cyclone was only available in Silver color.

    Size: 19x8.0"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $4,400
    Tire Spec: Pirelli Sottozero 3 - 245/45R19 98W (Overall Diameter: 27.7" / Revolutions Per Mile: 751)


    21 inch Tesla Model S Turbine Wheel

    21" Tesla Model S Turbine Wheel

    This wheel was the first wheel option available when ordering a Tesla Model S. It came in two set ups: square and staggered. Performance variants such as the P85+ received the staggered set up with Michelin Pilot Sport PS2 while other trims received square set ups with Continental ExtremeContact DWS06. The 21" Turbine was available in silver or gray color.

    Size: 21x8.5" Front, 21x9.0" Rear
    Offset: +40
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 35.2 lbs Front, 38 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $4,500 or $6,000 via Tesla Shop
    Tire Spec: Continental ContisportContact 5P or Continental ExtremeContact DWS06 - 245/35ZR21 96Y XL Front, 265/35ZR21 101Y XL (Overall Diameter: 27.8" Front, 28.3" Rear / Revolutions Per Mile: 747 Front, 734 Rear); Michelin Pilot Sport PS2 - 245/35ZR21 96Y XL Front, 265/35ZR21 101Y XL (Overall Diameter: 27.8" Front, 28.3" Rear / Revolutions Per Mile: 747 Front, 734 Rear)


    21 inch Tesla Model S Arachnid Wheel

    21" Tesla Model S Arachnid Wheel

    This wheel is not available when ordering a Tesla Model S. It could formerly be ordered as a wheel and tire package from the Tesla store, and as of late has disappeared from the Tesla online store. The 21" Turbine was available in silver or matte black color.

    Size: 21x8.5" Front, 21x9.0" Rear
    Offset: +40
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 27.85 lbs Front, 28.75 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Tesla Option: $7,600
    Tire Spec: Continental ContisportContact 5P - 245/35ZR21 96Y XL Front, 265/35ZR21 101Y XL (Overall Diameter: 27.8" Front, 28.3" Rear / Revolutions Per Mile: 747 Front, 734 Rear); Michelin Pilot Sport PS2 - 245/35ZR21 96Y XL Front, 265/35ZR21 101Y XL (Overall Diameter: 27.8" Front, 28.3" Rear / Revolutions Per Mile: 747 Front, 734 Rear)


    Offered by T Sportline:

    As the World's First Tesla Tuner, we engineer our wheels to fit within the factory parameters of your Model S. We use the hashtag motto #alloriginal, which means our wheels use the following:

    • The factory Tesla center caps. (COLOR MATCHED T Sportline center cap included with every wheel.)
    • The factory lug nuts
    • The factory tires.
    • The factory tire pressure sensors.

    The fact that we have designed all our wheels to fit all the factory hardware alleviates the need to fiddle with aftermarket lug nuts, branded center caps and different tire sizes. All you need to do is swap the wheels!

    19 inch Tesla Model S TSS Tesla Aftermarket Wheel

    19" TSS Wheel - Flow Forged

    The T Sportline TSS wheel is intended for the Model S owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 19" TSS is load rated at 900 kg/1,980 lbs.

    Size: 19x8.5"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 23.7 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,160 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    19 inch Tesla Model S TST Tesla Aftermarket Wheel

    19" TST Wheel - Flow Forged

    The T Sportline TST wheel is intended for the Model S owner looking for a similar appearance to the first version 21" factory Turbine wheel on a 2012 - 2019 Model S. Each 19" TST is load rated at 900 kg/1,980 lbs.

    Size: 19x8.5"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 24.4 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $1,900 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    19 inch Tesla Model S TST Tesla Aftermarket Wheel

    19" TST Wheel - Cast (Discontinued)

    The T Sportline TST wheel is intended for the Model S owner looking for a similar appearance to the first version 21" factory Turbine wheel on a 2012 - 2019 Model S. Each 19" TST is load rated at 750 kg/1,650 lbs.

    Size: 19x8.5"
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29 lbs
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $1,700 per set of four
    Finishes: Metallic Gray, Satin Black, and Gloss Black


    20 inch Tesla Model S TSR Tesla Aftermarket Wheel

    20" TSR Wheel - Flow Forged

    The T Sportline TSR wheel is intended for the Model S owner looking for a similar appearance to the Tesla Roadster wheel. Each 20" TSR is load rated at 900 kg/1,980 lbs.

    Size: 20X9.0" Front, 20X10.0" Rear
    Offset: +35
    PCD: 5X120
    Center Bore: 64.1mm
    Weight: 20x9.0": TBD, 20x10": 29.6 lbs
    Lug Nut Spec: 21mm Hex, 14X1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,700 per set of four
    Finishes: Satin Black


    20 inch Tesla Model S TSV Tesla Aftermarket Wheel

    20" TSV Wheel - Flow Forged

    The T Sportline TSV wheel is intended for the Model S owner looking for a similar appearance to the 21" factory Uberturbine wheel on a Model Y. Each 20" TSV is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10.0" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 33 lbs Front, 35.05lbs Rear (Estimated)
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,600 per set of four
    Finishes: Satin Gray and Satin Black


    20 inch Tesla Model S TS5 Tesla Aftermarket Wheel

    20" TS5 Wheel - Flow Forged

    The T Sportline TS5 wheel is intended for the Model S owner looking for a similar appearance to the 20" factory Zero G wheel from the Tesla Model 3 Track Package. Each 20" TS5 is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10.0" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 26.75 lbs Front, 29.8 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,600 per set of four
    Finishes: Satin Gray and Satin Black


    20 inch Tesla Model S TSS Tesla Aftermarket Wheel

    20" TSS Wheel - Flow Forged

    The T Sportline TSS wheel is intended for the Model S owner looking for a similar appearance to the 21" factory Arachnid wheel on a Model S. Each 20" TSS is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29.7 Front, 30.45 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,500 per set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    20 inch Tesla Model S TST Tesla Aftermarket Wheel

    20" TST Wheel - Flow Forged

    The T Sportline TST wheel is intended for the Model S owner looking for a similar appearance to the first version 21" factory Turbine wheel on a Model S. Each 20" TST is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 28.8 lbs Front, 31 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $2,100 for a set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    20 inch Tesla Model S TST Tesla Aftermarket Wheel

    20" TST Wheel - Cast (Discontinued)

    The T Sportline TST wheel is intended for the Model S owner looking for a similar appearance to the first version 21" factory Turbine wheel on a Model S. Each 20" TST is load rated at 900 kg/1,980 lbs.

    Size: 20x9.0" Front, 20x10" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 32.8 lbs Front, 34.8 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $1,800 for a set of four
    Finishes: Space Gray, Satin Black, and Gloss Black


    21 inch Tesla Model S TS112 Tesla Aftermarket Wheel

    21" TS112 Wheel - Fully Forged

    Size: 21x9.0" Front, 21x9.5" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 31 lbs Front, 29 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,000 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    21 inch Tesla Model S TS114 Tesla Aftermarket Wheel

    21" TS114 Wheel - Fully Forged

    Size: 21x9.0" Front, 21x9.5" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29.4 lbs Front, 29.2 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,000 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    21 inch Tesla Model S TS115 Tesla Aftermarket Wheel

    21" TS115 Wheel - Fully Forged

    Size: 21x9.0" Front, 21x9.5" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 27.4 lbs Front, 26 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,000 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    21 inch Tesla Model S TS117 Tesla Aftermarket Wheel

    21" TS117 Wheel - Fully Forged

    Size: 21x9.0" Front, 21x9.5" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 29 lbs Front, 28.5 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,000 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    21 inch Tesla Model S TS118 Tesla Aftermarket Wheel

    21" TS118 Wheel - Fully Forged

    Size: 21x9.0" Front, 21x9.5" Rear
    Offset: +35
    PCD: 5x120
    Center Bore: 64.1mm
    Weight: 30.2 lbs Front, 27.55 lbs Rear
    Lug Nut Spec: 21mm Hex, 14x1.50 Thread
    Lug Nut Torque Spec: 129lb-ft
    Price: Starting from $6,000 per set of four
    Finishes: Matte Black, Gloss Black, Anthracite Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black


    //
