The Tesla Model Y Wheel and Tire Guide

The Tesla Model Y Wheel and Tire Guide

Updated 08/07/2020




19" Tesla Model Y Power Sports or 'Gemini' Wheel



  • Size: 19x9.5" Front & Rear
  • Offset: +45
  • PCD: 5X114.3
  • Center Bore: 64.1mm
  • Weight: 29.6 lbs
  • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
  • Lug Nut Torque Spec: 129 lb-ft
  • Price: No Charge
  • Tire Spec: Continental ProContact RX 255/45-19 104W Front, Rear
  • Details: This is the base model wheel that comes with every Tesla Model Y free of charge.

20" Tesla Model Y Induction Wheel



  • Size: 20X9.5" Front & Rear
  • Offset: +45
  • PCD: 5X114.3
  • Center Bore: 64.1mm
  • Weight: 31.55 lbs
  • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
  • Lug Nut Torque Spec: 129 lb-ft
  • Price: $2,000
  • Tire Spec: Goodyear Eagle F1 Asymmetric 5 255/40-20 XL 101W Front, Rear
  • Details: This is the optional wheel that costs an additional $2,000 when ordering a Tesla Model Y Long Range Dual Motor.



21" Tesla Model Y Überturbine Wheel



  • Size: 21X9.5" Front, 21X10.5" Rear
  • Offset: +40 Front, +48 Rear
  • PCD: 5X114.3
  • Center Bore: 64.1mm
  • Weight: 21x9.5" = 38.05 lbs, 21x10.5" = 38.95 lbs
  • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
  • Lug Nut Torque Spec: 129 lb-ft
  • Price: No Charge
  • Tire Spec: Pirelli P Zero 255/35-21 XL 98W Front, 275/35-21 XL 103W Rear
  • Details: This is included in the Performance Tesla Model Y with Performance Upgrade Option free of charge.

model y wheels model y aftermarket model y mods model y wheel size model y tires model y weight model y lug nut model y torque model y wheel price model y




What we will offer at T Sportline:

As the World's First Tesla Tuner, we engineer our wheels to fit within the factory parameters of your Model Y. We use the hashtag motto #alloriginal, which means our wheels use the following: 1. The factory Tesla center caps. (We do include our own COLOR MATCHED center cap with every wheel.) 2. The factory lug nuts. 3. The factory tires. 4. The factory tire pressure sensors. The fact that we've designed all our wheels to fit all the factory hardware alleviates the need to fiddle with aftermarket lug nuts, aftermarket branded center caps and different tire sizes. All you need to swap is the wheels and use your factory hardware. Owning a set of aftermarket wheels could not be easier!

19" TSS Wheel - Flow Forged

  • Size: 19x9.5"
  • PCD: 5X114.3
  • Center Bore: 64.1mm
  • Weight: 25.25 lbs
  • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
  • Lug Nut Torque Spec: 129 lb-ft
  • Price: Starting from $1,760 per set of four
  • Finishes: Brilliant Silver, Space Gray, Matte Black, and Gloss Black.
  • Details: The T Sportline TSS is intended for the Model Y owner looking for a similar look to the 21" factory Arachnid wheel on a Model S. Each 19" TSS is load rated at 900kg/1,980 lbs.



19" TST Wheel - Flow Forged

  • Size: 19x9.5"
  • PCD: 5X114.3
  • Center Bore: 64.1mm
  • Weight: 25.95 lbs (Estimated)
  • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
  • Lug Nut Torque Spec: 129 lb-ft
  • Price: Starting from $1,560 per set of four
  • Finishes: Brilliant Silver, Space Gray, Matte Black, and Gloss Black.
  • Details: The T Sportline TST is intended for the Model Y owner looking for a similar look to the version 1 21" factory Turbine wheel on a Model S. Each 19" TST is load rated at 900kg/1,980 lbs.



    19" Falcon Y Limited Edition - Flow Forged

    • Size: 19X10" Front & Rear
    • Offset: +40
    • PCD: 5X114.3
    • Center Bore: 64.1mm
    • Weight: 24.9 lbs
    • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
    • Lug Nut Torque Spec: 129 lb-ft
    • Price: $2,000 per set of four
    • Finishes: Ecliptic Black, Moonrock Gray, and Jupiter Bronze.
    • Details: The T Sportline Falcon Y Limited Edition Wheel is inspired by the success of Space X and exclusively manufactured for the Tesla Model 3 & Y. Each 19" Falcon Y Limited Edtion Wheel is load rated at 750kg/1,650 lbs.



    20" TSS Wheel - Flow Forged

    • Size: 20X10.0" Front & Rear
    • Offset: +40
    • PCD: 5X114.3
    • Center Bore: 64.1mm
    • Weight: 30.45 lbs
    • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
    • Lug Nut Torque Spec: 129 lb-ft
    • Price: Starting from $1,760 per set of four
    • Finishes: Space Gray, Matte Black, and Gloss Black.
    • Details: The T Sportline TSS is intended for the Model Y owner looking for a similar look to the 21" factory Arachnid wheel on a Model S. Each 20" TSS is load rated at 900kg/1,980 lbs.



    20" TST Wheel - Flow Forged


    • Size: 20X10.0" Front & Rear
    • Offset: +40
    • PCD: 5X114.3
    • Center Bore: 64.1mm
    • Weight: 30.35 lbs
    • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
    • Lug Nut Torque Spec: 129 lb-ft
    • Price: Starting from $1,660 per set of four
    • Finishes: Space Gray, Matte Black, and Gloss Black
    • Details: The T Sportline TST is intended for the Model Y owner looking for a similar look to the version 1 21" factory Turbine wheel on a Model S. Each 20" TST is load rated at 900kg/1,980 lbs.






      20" Falcon Y Limited Edition - Flow Forged

      • Size: 20x10" Front & Rear
      • Offset: +40
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: 25.65 lbs
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: $2,400 per set of four
      • Finishes: Ecliptic Black, Moonrock Gray, and Jupiter Bronze.
      • Details: The T Sportline Falcon Y Limited Edition Wheel is inspired by the success of Space X and exclusively manufactured for the Tesla Model 3 & Y. Each 20" Falcon Y Limited Edtion Wheel is load rated at 750kg/1,650 lbs.



      20" TY114 Forged Tesla Model Y Wheel

      • Size: 20x10"
      • Offset: +40
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: ~25 lbs (Estimated)
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: Starting from $4,200 per set of four
      • Finishes: Matte Black, Gloss Black, Matte Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black.






      20" TY117 Forged Tesla Model Y Wheel

      • Size: 20X10"
      • Offset: +40
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: ~25 lbs (Estimated)
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: Starting from $4,200 per set of four
      • Finishes: Matte Black, Gloss Black, Matte Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black.






      20" TY118 Forged Tesla Model Y Wheel

      • Size: 20X10"
      • Offset: +40 Rear
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: ~26 lbs (Estimated)
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: Starting from $4,200 per set of four
      • Finishes: Matte Black, Gloss Black, Matte Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black.

      21" TY114 Forged Tesla Model Y Wheel

      • Size: 21x9.5" Front, 21x10.5" Rear
      • Offset: +32 Front, +40 Rear
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: 21x9.5"= 29.2 lbs, 21x10.5" = 30 lbs (Estimated)
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: Starting from $4,600 per set of four
      • Finishes: Matte Black, Gloss Black, Matte Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black.






      21" TY117 Forged Tesla Model Y Wheel

      • Size: 21x9.5" Front, 21x10.5" Rear
      • Offset: +32 Front, +40 Rear
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: 21x9.5"= 28.5 lbs, 21x10.5" = 29.4 lbs
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: Starting from $4,600 per set of four
      • Finishes: Matte Black, Gloss Black, Matte Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black.






      21" TY118 Forged Tesla Model Y Wheel

      • Size: 21x9.5" Front, 21x10.5" Rear
      • Offset: +32 Front, +40 Rear
      • PCD: 5X114.3
      • Center Bore: 64.1mm
      • Weight: 21x9.5"= 27.55 lbs, 21x10.5" = 28.85 lbs
      • Lug Nut Spec: 21mm Hex, 14X1.50 Thread
      • Lug Nut Torque Spec: 129 lb-ft
      • Price: Starting from $4,600 per set of four
      • Finishes: Matte Black, Gloss Black, Matte Gray, Brush Satin, Velocity Red, Imperial Red, and Diamond Black.
